I14R Impact Crusher

The Anaconda I14R Impact Crusher is a closed circuit crushing solution designed with durability, improved material flow and increased production capabilities in mind. Fitted with a with a standard 3-bar rotor or optional 4-bar rotor on a McLanahan 1,195 mm x 1,295 mm (47” x 51”) Impact Chamber, the I14R Impact Crusher features a recirculating conveyor that can be rotated from a closed loop position to a stockpiling position. The I14R’s recirculating system is equipped with a quickly detachable full-length top and bottom 4.27 m x 1.83 m (14’ x 6’) double-deck screen for producing a high-quality crushed and screened final product in one pass.

Ideal for large scale producers and contract crushing customers, the I14R Impact Crusher is built for aggregate crushing, C&D recycling, asphalt processing and concrete recycling applications. Weighing 56,800 kg (125,000 lbs), the I14R is light enough to be transported with a standard semi-trailer, reducing the need for permitting and special transport restrictions.
